Frequency Inverter Omron M1 | 0.4 kW | 200 VAC | 1-phase | max. 590 Hz
Inverter Omron MX2 | 0.4 kW | 200 V | 1-phase
Frequency inverters of the series MX2 are developed for versatile tasks of drive specially suited for applications with a high priority on cost efficiency. By its vector regulation it is very well suitable to operate with HF-spindles, since it offers a high starting torque of up to 200%. The MX2 presents the ideal combination of innovative ISPM-technology, powerful performance and practical design.We recommend to install a line-filter in front of the converter, or order a converter set incl. line filter!
For programming via mini-USB the CX software is required.
This is not included in delivery.
Technical Data:
- Frequency Inverter Omron MX2 0.4 kW
- Single-phase 200 ... 240 VAC, 50 ... 60 Hz
- 0.5 ... 400 Hz
- Vector regulated up to 400 Hz
- Integrated brake chopper
- Avoidance of overcurrent disconnections
- Dualrating
- Secure stop after ISO 13849-1 PLd
- Starting torque 200%
- Positioning and PM drive control
- Programming over Mini-USB
- integrated PLC-Function
Datasheet OMRON 3G3M1-AB004Manufacturer: | Responsible person: |
